21
4 Pre-observation/pre-operation preparation and inspection
• Be careful to not pinch your hand or anything else when lowering the
handle.
Hang the main unit
When hanging the main unit to do observation, hook an S-hook, string or
other item onto the handle.
Set up the main unit on a tripod
Attach the tripod platform to the main unit to use a tripod to do observations.
• When fixing the main unit to the tripod, mount it so the
tripod platform does not run up on the protrusion on
the rear of the main unit.
Fixing the tripod with the platform installed at an angle
may cause the main unit to fall off.
You can use a square platform that measures 45 mm
or less from the center of the tripod screw.
To Next Page
