9 Specifications
9.1 Operating environment
CAUTION
• Meeting operating environment specifications does not constitute any guarantee against damage to or
malfunction of the instrument.
• Use AC adapter and battery charger indoors (normal temperature).
9.2 Main specifications
Operating temperatures
Insertion tube
In air: -25 to 80°C
In water: 10 to 30
°C
Parts other than
the insertion tube
In air: -10 to 40°C (battery-powered operation)
0 to 40
°C (AC adapter-powered operation)
Operating atmospheric pressure
Insertion tube In air: Normal pressure (1,013 hPa)
In water: 1,013 to 1,135 hPa
Parts other than
the insertion tube
In air: Normal pressure (1,013 hPa)
Operating environment humidity
All parts 15 to 90% (relative humidity)
Liquid resistance
Insertion tube No trouble when exposed to machine oil, light oil or 5% saline solution.
Parts other than
the insertion tube
Waterproofing
Insertion tube Waterproof construction. Can be used underwater.
Parts other than
the insertion tube
Drip-proof construction. Use in water is not supported. The instrument is not drip-proof
if the battery cover, video connector cap, or AC adapter connector cap is open.
Optical system
Field of view
80°
Direction of view Forward
Depth of field 3 mm to 70 mm
Illumination Light from the white LED in the control unit is guided to the distal end via the light guide.
Distal end
Outer diameter Less than 2.4 mm.
Distal end rigid
section length
10 mm
Angulation
135°
* In UP and DOWN directions (when insertion tube is straight)
Flexible section
Flexibility Fixed hard tube from the distal end to the control unit.
Outer diameter Less than 2.4 mm.
Total length 1.2 m
