51
9 Specifications
• The images recorded with the instrument can be displayed on a computer, etc., but playback on the
instrument of images recorded with an image recording device such as a digital camera or a computer is
not supported.
• Windows Media Player is either a registered trademark or trademark of Microsoft Inc. in the U.S. and/or
other countries.
• Foxit PDFSDK Copyright ©2010, Foxit Software Company www.foxitsoftware.com, All rights reserved.
Control unit
Scope unit
replacement
The scope unit (insertion tube + angulation control unit) can be replaced on the button
control unit.
Dimensions 49(W) x 59(H) x 334(L) mm (without insertion tube and cable)
Weight Approx. 300g (without insertion tube and universal cable)
LCD panel 6.5" TFT full-color low ambient light reflective type
Input/output connector
Video signal
outputs
One video signal output (for external devices)
Composite (VBS) video output (for live image)
One RCA jack output
USB connector A connector, USB 2.0 compatible
Power supply
Battery Model: Manufactured by INSPIRED ENERGY NC2040OL24
Nominal voltage: 10.8 V
Battery powered operating time: 150 minutes (based on new battery)
For details, refer to the instruction manual of your battery.
AC adapter Input voltage: 100 V to 240 V AC
Frequency: 50/60 Hz
Output voltage: 12 V
For details, refer to the instruction manual of the AC adapter.
Battery charger Model: Manufactured by INSPIRED ENERGY CH5000C or CH5000X
Input Voltage: 90 V to 260 V AC
Frequency: 50/60 Hz
For details, refer to the instruction manual of the battery charger.
Operating voltage range 7.5 V to 12.6 V (battery-powered operation)
11.4 V to 12.6 V (AC adapter-powered operation)
Power consumption MAX 9 W
Dimensions 239 (W) x 217 (H) x 99 (D) mm
Still image recording
Resolution NTSC: H640 x V480 (pixels)
PAL: H768 x V576 (pixels)
Recording format Files are stored as compressed JPEG format (Exif 2 compliant).
Still image retrieval
Restrictions Images recorded on the instrument can be played back.
Moving image recording
Resolution H640 x V480 (pixel)
Recording format AVI MPEG-4 formats. Compression rates fixed.
Playback on Windows Media Player supported.
(Provided that Windows Media Player Ver. 7 and Direct X7.1 or later are installed)
Moving image playback
Restrictions Images recorded on the instrument can be played back.
Carrying case dimensions and weight
Dimensions 600 (W) x 426.5 (H) x 133 (D) mm
23.62 (W) x 16.79 (H) x 5.16 (D) inch
Weight Approx. 3kg (7.4kg with all accessories stowed)
Manufacturer OLYMPUS CORPORATION TOKYO, JAPAN
