22
Item
SPECIFICATIONS
Specification
1. Zoom microscope body
MVX-ZB10
Zoom magnification system.
Zoom drive system: Horizontal knob.
Click stop ON-OFF switchable per zoom ratio.
Zoom ratios: 10 (0.63X to 6.3X).
Zoom ratio indications: 0.63, 0.8, 1, 1.25, 1.6, 2, 2.5, 3.2, 4, 5, 6.3.
Objective mount: Threaded mount
Built-in aperture iris diaphragm.
2. Objective
MVPLAPO 0.63X: NA 0.15, WD 87 mm, FN 22.
MVPLAPO 1X: NA 0.25, WD 65 mm, FN 22.
MVPLAPO 2XC: NA 0.5, WD 20 mm, FN 22., with correction collar.
3. Eyepiece
* 24 mm dia., 1.5 mm thick eyepiece
micrometer disk can be inserted.
WHN10X-H*: FN 22, with diopter adjustment ring.
4. Focusing assembly
MVX-FOF
Focusing system: Rack &pinion roller guide (with coarse focus adjustment knob
rotation tension adjustment ring).
With built-in high-load counterbalance.
Coaxial coarse/fine focus adjustment knobs.
Coarse focus adjustment knob stroke: 80 mm
Coarse knob stroke per turn: 36.8 mm.
Fine focus adjustment knob stroke: 80 mm.
Fine knob stroke per turn: 1.5 mm.
5. Tilting trinocular head
MVX-TTRS
Tilting angle: 0° to 23°
Light path selection: 2 steps (Bi 100% or TV/Photo 100%).
Interpupillary distance adjustment: 51 to 76 mm.
Eyepiece clamping knob provided.
Eyepiece: WHN10X-H
6. Coaxial fluorescence illuminator
MVX-RFA
Illumination magnification: 1X (FN 22).
Observation switching: Mirror unit turret.
Number of mountable fluorescence mirror units: 3 (with idle positions).
Field iris diaphragm provided (centering possible).
Shutter provided.
Filter slider knob provided (2 filter pockets + 1 idle position).
Available observation methods: Reflected light fluorescence and transmitted light.
7. Lamp housing for mercury burner U-LH100HG: Lamp housing for 100 W mercury burner.
U-LH100HGAPO: Apo lamp housing for 100 W mercury burner.
Mercury burner: USH-103OL (OLYMPUS) or HBO103W/2 (OSRAM)
Power Supply Unit: U-RFL-T
8. Operating environment · Indoor use.
· Altitude: Max. 2000 meters (6440 ft/).
· Ambient temperature:5° to 40°C (41° to 104°F).
· Relative humidity: 80% for temperatures up to 31°C (88°F), decreasing linearly
through 70% at 34°C (93°F), 60% at 37°C (99°F) to 50%
relative humidity at 40°C (104°F).
· Supply voltage fluctuations: ±10%.
· Pollution degree: 2 (in accordance with IEC60664).
· Installation (overvoltage) category: II (in accordance with IEC60664)
