23
MVX10
OPTICAL CHARACTERISTICS
Total Magnification/Actual Field
· Total magnification = Objective power x Zoom ratio x Eyepiece magnification
· Actual field area =
Eyepieces
Eyepiece FN
Objective power x Zoom ratio
Objective WHN10X-H (Field number: 22)
Total magnification Actual field (mm)
MVPLAPO 0.63X 4X to 40X 55.4 to 5.54
MVPLAPO 1X 6.3X to 63X 34.9 to 3.49
MVPLAPO 2XC 12.5X to 125X 17.4 to 1.74
