4
Figure 1-2. CN9000A Series Replacement Output Board
Numbering Information
TABLE 1-2
CN9000A REPLACEMENT OUTPUT BOARD DETAILS
MODEL OUTPUT 1 OUTPUT 2
BD9011A Relay Relay
BD9021A 5VDC SSD Relay
BD9012A Relay 5VDC SSD
BD9022A 5VDC SSD 5VDC SSD
BD9031A* 1 Amp Triac SSR Relay
BD9041A*† 4-20 mA DC Relay
BD9051A*† 0-10 VDC Relay
*Requires that BD9021A is already installed in the controller.
†For 230 VAC models, add "-230VAC" to the part number
CODE Output No. 2
1 3A Mech Relay
2 5VDC SSD
CODES for Output No. 1
1 5A Mechanical Relay
2 5VDC Solid State Driver (Pulse)
3 1A Triac SSR
4 4-20 mA DC
5 0-10 VDC
BD90
A
