TABLE 3-4 (Cont'd)
FUNCTION
.4 (Cont'd) CYCLE TIME/ON-OFF (OUTPUT 1)
(Op#).(Fn#) Parameter/Comment
0.4 20 sec (Default setting)
*1.4 1 sec
*2.4 5 sec
3.4 10 sec
4.4 30 sec
5.4 60 sec
6.4 Analog Outputs
(4-20 mA DC or 0-10VDC only)
7.4 ON/OFF
8.4 0.3 sec
*9.4 2 sec
*10.4 3 sec
*11.4 7 sec
12.4 14 sec
13.4 45 sec Operational
14.4 AT value
15.4 Latest calculated AT value
This is the percent of the Span (allowable setpoint range) both
below and above setpoint in which proportion action is active.
Output is 100% at the bottom of the proportion band, 0% at the
top, and proportional in between. If ON/OFF Control was selected
(Function .4, Option 7), then this selection represents deadband
(hysteresis), or the amount the temperature must fall after reaching
setpoint before the relay returns to original state.
*not recommended with mechanical relay
.5 PROPORTIONAL BAND/DEADBAND (OUTPUT 1)
