Omega C9000A SERIES User Manual

26
(Op#).(Fn#) Parameter/Comment
SP1 Proportional SP1 Hysteresis in
ON/OFF
band/Gain mode (Deadband)
0.5 2.5% x range 1.25% x span
1.5 0.5% 0.25%
2.5 1 % 0.5%
3.5 2% 1 %
4.5 3% 1.5%
5.5 5% 2.5%
6.5 10% 5%
7.5 20% 10%
8.5 1.5% 0.75%
9.5 4% 2%
10.5 6% 3%
11.5 7% 3.5%
12.5 8% 4%
13.5 14% 7%
14.5 100% 50%
*15.5 AT value
TABLE 3-4 (Cont'd)
FUNCTION
.5 (Cont'd) PROPORTIONAL BAND/DEADBAND (OUTPUT 1)
Refer to Section 5.6. Set to OUT (Option 1) if Proportional Only
Control is desired.
*Note: You will not see 15.5 on the display. The actual AT value, in
%, will appear at the left side of the display.
.6 DERIVATIVE TIME/RATE (OUTPUT 1)
(Op#).(Fn#) Parameter/Comment
0.6 25 sec
1.6 OUT
2.6 5 sec
3.6 10 sec
4.6 50 sec
5.6 100 sec
(Option list continued on next page)
