Omega C9000A SERIES User Manual

27
TABLE 3-4 (Cont'd)
FUNCTION
.6 (Cont'd) DERIVATIVE TIME/RATE (OUTPUT 1)
(Op#).(Fn#) Parameter/Comment
0.7 1.5 x proportional band
1.7 0.5 x proportional band
2.7 1.0 x proportional band
3.7 2.0 x proportional band
4.7 2.5 x proportional band
5.7 3.0 x proportional band
6.7 4.0 x proportional band
*7.7 AT value
(Op#).(Fn#) Parameter/Comment
6.6 200 s
7.6 1 sec
8.6 2 sec
9.6 3 sec
10.6 7 sec
11.6 15 sec
12.6 20 sec
13.6 35 sec
14.6 75 sec
*15.6 AT value
*Note: You will not see 15.6 on the display. The actual AT value, in
seconds, will appear at the left side of the display.
.7 DERIVATIVE APPROACH CONTROL (DAC) (OUTPUT 1)
Used to eliminate derivative action during system warm-up time.
Refer to Section 5.7.
*Note: You will not see 7.7 on the display. The actual AT value in
multiples of the proportional band will appear at the left side of the
display.
