28
(Op#).(Fn#) Parameter/Comment
0.8 5 min (300 sec)
1.8 OUT: Manual Reset (Function .1 used)
2.8 0.5 min (30 sec)
3.8 1 min (60 sec)
4.8 2 min (120 sec)
5.8 3 min (180 sec)
6.8 10 min (600 sec)
7.8 18 min (1080 sec)
8.8 0.2 min (12 sec)
9.8 7 min (420 sec)
10.8 13 min (780 sec)
11.8 25 min (1500 sec)
12.8 33 min (1980 sec)
13.8 43 min (2580 sec)
*14.8 AT value
TABLE 3-4 (Cont'd)
FUNCTION
.8 INTEGRAL TIME (OUTPUT 1)
Also known as Automatic Reset. Refer to Section 5.5.
(Op#).(Fn#) Parameter/Comment
* 0.10 ON/OFF
*1.10 1 sec
*2.10 5 sec
*3.10 10 sec
(Options continued on next page)
*Note: You will not see 14.8 on the display. The actual AT value in
minutes will appear at the left side of the display
.9 SENSOR OFFSET (CALIBRATION)
.10 CYCLE TIME/ON-OFF (OUTPUT 2)
Provides correction at one single temperature. Adjust in 1° steps
(±127° max). Refer to Figure 6-1 for the Sensor Error Graph.
Cycle time for second setpoint. Set similarly to first setpoint
(Function .4). Note that SP2 must first be activated in
Function .19. The preset Default setting for SP2 is ON/OFF.
*not recommended with mechanical relay
To Next Page
