Page #35 background image
29
TABLE 3-4 (Cont'd)
FUNCTION
.10 (Cont'd) CYCLE TIME/ON-OFF (OUTPUT 2)
Op#).(Fn#) SP2 Proportional SP2 Hysteresis in
Band/Gain ON/OFF mode
(Deadband)
0.11 2.5% x range 1.25%
1.11 0.5% x range 0.25%
2.11 1% x range 0.5%
3.11 2% x range 1%
4.11 3% x range 1.5%
5.11 5% x range 2.5%
6.11 10% x range 5%
7.11 20% x range 10%
8.11 1.5% x range 0.75%
9.11 4% x range 2%
10.11 6% x range 3%
11.11 7% x range 3.5%
12.11 8% x range 4%
13.11 14% x range 7%
14.11 100% x range 50%
(Op#).(Fn#) Parameter/Comment
4.10 20 sec
5.10 60 sec
6.10 Not Used
7.10 30 sec
*8.10 2 sec
*9.10 3 sec
*10.10 7 sec
11.10 14 sec
12.10 45 sec
Non-linear ranges for Cool Strategy:
13.10 0.15-10 sec
14.10 0.15-20 sec
15.10 0.06-15 sec
*not recommended with mechanical relay
.11 PROPORTIONAL BAND/DEADBAND (OUTPUT 2)
Set similarly to first setpoint Proportional Band (Function .5).
