41
TABLE 3-6 (Cont'd)
FUNCTION
.30 OUTPUT 2 DIRECT/REVERSE
Allows action of second output to be set to direct acting for cooling
(standard) or reverse acting.
WARNING
Inverting output may affect controller
failsafe characteristics.
Selection should only be made by qualified personnel. Consult
OMEGA if you are not sure of your application. This function is not
available with Software Version 3. Refer to Function .23.
(Op#).(Fn#) Parameter/Comment
0.30 Direct Acting (cooling)
1.30 Reverse Acting (Heating)
(Op#).(Fn#) Parameter/Comment
0.31 ON when logically on (standard)
1.31 OFF when logically on (reversed)
(Op#).(Fn#) Parameter/Comment
0.32 Normal (2% range/segment)
1.32 High (1%)
2.32 Low (4%)
.31 OUTPUT 2 LED OPERATION
Allows reversal of action of SP2 LED (e.g. change to on when
logically off and off when logically on). Refer also to Function 19.
.32 ERROR INDICATION RESOLUTION
Allows adjustment in the indication of the deviation from setpoint.
To Next Page
