Omega C9000A SERIES User Manual

TABLE 8-1
TEMPERATURE DISPLAY-LINEARITY AND DEFAULT
SETTINGS
SENSOR LINEARIZED LINEARITY DEFAULT
TYPE RANGE* TOLERANCE ± SETPOINT ADJ*
J0 to 800°C 1°C 400°C
K0 to 1200°C 1°C 400°C
N0 to 1200°C 1°C 400°C
R0 to 300°C 5°C 1600°C
300 to 1600°C 2°C
S0 to 300°C 5°C 1600°C
300 to 1600°C 2°C
T -200 to 250°C 2°C 250°C
E0 to 600°C 1°C 500°C
B 300 to 1800°C 6°C 1600°C
J DIN 0 to 800°C 1°C 400°C
Pt100 RTD -200 to 250°C 0.25°C 200°C
250 to 400°C 0.5°C
*Maximum display in °F is 1999 for all thermocouple types
TABLE 8-2
LINEAR PROCESS INPUT DISPLAY RANGES
76
LINEARITY
RANGE LINEAR INPUT DISPLAY TOLERANCE*
1 0-20 mV 0-100 ±1.5%
2 4-20 mV 0-100 ±1.5%
3 0-20 mV 0-1000 ±1.5%
4 4-20 mV 0-1000 ±1.5%
5 0-20 mV 0-2000 ±1.5%
*Minimum impedance: 100 k ohms
Linear Process input ranges are selectable in Function .16.

Omega C9000A SERIES Specifications

General

Brand	Omega
Model	C9000A SERIES
Category	Temperature Controller
Language	English
