DPF20 Frequency, rate, total or period counter Instruction Manual
1.19 Conguraon menu (cont.)
The ‘On Power Up’ (‘on.Pu’) menu congures funcons to apply at start-up. It
applies only to instrument restart aer power loss. It does not apply to instru-
ment restart due to change in conguraon.
• parameter ‘Delay’ (‘dLAy’) assigns a waing me in seconds. The instrument
waits the congured me before starng normal funcon. During this waing
me, the display shows all decimal points on in ash mode, all alarms are in
‘oFF’ state, there is no signal acquision and there is no communicaons or
control being performed. Aer the congured me is over, the instrument
starts in normal funcon. Delay value between 0 and 200 seconds.
• the ‘Reset’ (‘rSt’) parameter will execute a reset of the counter each me the
instrument is restarted.
1.19.15 Menu ‘On Power Up’
Tools
Key UP
(‘fast access’)
Memory of
maximum
Memory of
minimum
Setpoint 1
Setpoint 2
Setpoint 3
Memory of
cycles
Preset value
On power-up
Delay Seconds
Reset
The ‘UP’ (5) key at the front of the instrument gives access to a list of func-
ons congurable by the operator. See secon 1.17 for an explanaon on how
to operate the ‘fast access’ menu.
The ‘Key UP (Fast access)’ (‘K.uP’) menu allows to select which funcons will
be accessible through the ‘fast access’ menu. Select ‘on’ to acvate each func-
on.
• the ‘Setpoint
1’ (‘ALr1’) funcon allows to visualize and modify the alarm 1
setpoint through the ‘fast access’ menu.
• the ‘Setpoint
2’ (‘ALr2’) funcon allows to visualize and modify the alarm 2
setpoint through the ‘fast access’ menu.
• the ‘Setpoint
3’ (‘ALr3’) funcon allows to visualize and modify the alarm 3
setpoint through the ‘fast access’ menu.
• the ‘Memory of maximum’ (‘MAX’) or ‘Memory of minimum’ (‘MIn’) func-
ons allow to visualize the maximum or minimum reading value stored in
memory. To reset this value, visualize the memory value at the ‘fast access’
menu with key UP (5) and when message ‘rSt’ is displayed, press (<) to re-
set.
• the ‘Memory of cycles’ (‘cYcL’) funcon allow to visualize and reset the
memory of cycles. To reset this value, visualize the memory value at the ‘fast
access’ menu with key UP (5) and when message ‘rSt’ is displayed, press (<)
to reset. The memory of cycles countes ‘+1’ each me a reset alarm occurs
(‘on_AL’ / ‘to_0’ or ‘to_P’) or a reset by ‘overrange’ / ‘underrange’ occurs.
• the ‘Preset value’ (‘PrSt’) funcon allows to visualize and modify the preset
value congured.
1.19.12 Fast access
If only a single funcon is selected for the ‘fast access’ menu, press-
ing the the ‘UP’ (5) key will shortly display the funcon name and
then automacally jump to the funcon value.
1.19.13 Super fast access
The ‘LE’ (3) key at the front of the instrument can be congured to
acvate a funcon.
• the ‘No funcon’ (‘nonE’) value assigns no funcon.
• the ‘Front reset’ (‘F.rSt’) value asigns the reset funon.
• the ‘Alarm unlock’ (‘A.Lck’) value assigns the manual unlock of the
alarms funcon, for instruments with the ‘Locked alarms’ (‘A.Lck’)
funcon acvated (see secon 1.19.11)
• the ‘Reset and alarm unlock’ (‘Fr.AL’) assigns the two previous
funcons to the same buon.
1.19.14 Menu ‘Key LE’
Key LE
Front reset
Alarm unlock
No funcon
Reset and alarm unlock
