Omega DPF20 Series User Manual

21
DPF20 Frequency, rate, total or period counter Instruction Manual
Password
Version
Factory reset
Minimum
Brightness
Maximum
Standard
Opon
1
Conguraon menu for the module installed at Opt.1
Opon
2
Conguraon menu for the module installed at Opt.2
Opon 3
Conguraon menu for the module installed at Opt.3
Le zeros
With le zeros
Without le zeros
Funcon counter (‘cn.1’)
Decimal point no
Counter conguraon
Mulplier x1
Divider /1
Preset 0
Mode up
‘FAST’ o
Sensor
Pulls on channel A no pull resistor
Pulls on channel B no pull resistor
Pulls on reset pull-up
Trigger 2,5 Vdc
Acvaon for channel A on rising edge (‘on_h’)
Excitaon voltage 5 Vdc
Anrrebound lter 0 mSeconds
Tools
Fast access (Key UP) o
‘On Power Up’
Delay 0 seconds
Key ‘LE’ reset funcon
Memory of maximum -199999
Memory of minimum 999999
Memory of cycles 0
Counter overrange ash
Counter underrange ash
Le zeros o
Vexc. control o
Password o
Brightness 3
Alarms 1,2 and 3
Acve o (disabled)
Type maximum
Setpoint 1000
Hysteresis 0 counts
Acvaon delay 0.0 seconds
Deacvaon delay 0.0 seconds
Setpoint 2 o
On Alarm connue
Inverted relay o
Locked alarms o
Factory conguraon for Ratemeter (‘cnF.6) and periodmeter (‘cnF.8)
modes.
Mulplier x1
Divider /1
Time windows 0.5
‘SLOW’ mode
tIME 0 (o)
nuMb 1
Recursive lter 0 (o)
Factory conguraon for output and control modules, see secon 2.
1.20 Full conguraon menu (cont.) 1.21 Factory conguraon
Control Vexc.
with Vexc. error control
without Vexc. error control
