DPF20 Frequency, rate, total or period counter Instruction Manual
At the ‘Password’ (‘PASS’) menu select a 6 digit code to block access
to the ‘conguraon menu’. Instrument conguraon will not be ac-
cessible to non authorized personnel. To acvate the ‘Password’ se-
lect ‘on’ and introduce the code.
The code will be requested when trying to access the ‘conguraon
menu’ (key ‘SQ’ (<)). The ‘fast access’ menu is not password pro-
tected.
The ‘Version’ (‘VEr’) menu informs of the current rmware version
installed in the module.
1.19.16 Menus ‘Overrange / underrange’
At the ‘Brightness’ (‘LIGh’) menu select the light intensity for the
front leds. With this funcon it is possible to adapt the instrument to
the environment light intensity.
1.19.18 Vexc. control
Menus ‘OPt.1’, ‘OPt.2’ and ‘OPt.3’ give access to the ‘conguraon
menus’ of the output and control modules installed at slots Opt.1,
Opt.2 and Opt.3.
See secon 2 for a list of output and control modules available for
each slot. The ‘conguraon menu’ of each module is described at
the User’s Manual of each module.
1.19.19 Funcon ‘Password’
At the ‘Factory reset’ (‘FAct’) menu, select ‘yes’ to load the default
factory conguraon for the instrument (see secon 1.21).
1.19.20 Factory reset
1.19.21 Firmware version
The ‘Counter overrange’ (‘c.orG’) and ‘Counter underrange’ (‘c.urG’)
parameters congure the behavior of the instrument when reading
is higher than ‘9999’ (overrange) or lower than ‘-1999’ (underrange).
Select ‘FLSH’ to enter reading into ash mode. Select ‘to_0’ to apply
a reset to ‘0’. Select ‘to_P’ to apply a reset to preset value.
1.19.22 Brightness
1.19.17 Le zeros
The ‘Le zeros’ (‘L.ZEr’) parameter controls the le zeros on or o.
1.19 Conguraon menu (cont.)
Password
Version
Factory reset
Minimum
Brightness
Maximum
Standard
Opon
1
Conguraon menu for the module installed at Opt.1
Opon
2
Conguraon menu for the module installed at Opt.2
Opon 3
Conguraon menu for the module installed at Opt.3
Counter
overrange
Flash
To zero
To preset
Counter
underrange
Flash
To zero
To preset
Le zeros
With le zeros
Without le zeros
Vexc. control
with Vexc. error control
without Vexc. error control
1.19.23 Access to oponal modules
The ‘Vexc control’ (‘V.ctr’) parameters enables the ‘Err.8’ message,
when consumpon requested to the excitaon voltage is higher than
the current the instrument can provide.
