DPF20 Frequency, rate, total or period counter Instruction Manual
This instrument has been designed and veried conforming to the 61010-1
CE Security Regulaon, for industrial applicaons.
Installaon of this instrument must be performed by qualied personnel
only. This manual contains the appropriate informaon for the installaon.
Using the instrument in ways not specied by the manufacturer may lead to
a reducon of the specied protecon level. Disconnect the instrument from
power before starng any maintenance and / or installaon acon.
The instrument does not have a general switch and will start operaon as
soon as power is connected. The instrument does not have protecon fuse,
the fuse must be added during installaon.
The instrument is designed to be panel mounted. An appropriate venlaon
of the instrument must be assured. Do not expose the instrument to excess
of humidity. Maintain clean by using a humid rag and do NOT use abrasive
products such as alcohols, solvents, etc.
General recommendaons for electrical installaons apply, and for proper
funconality we recommend : if possible, install the instrument far from
electrical noise or magnec eld generators such as power relays, electrical
motors, speed variators, ... If possible, do not install along the same conduits
power cables (power, motor controllers, electrovalves, ...) together with sig-
nal and/or control cables.
Before proceeding to the power connecon, verify that the voltage level
available matches the power levels indicated in the label on the instrument.
In case of re, disconnect the instrument from the power line, re alarm
according to local rules, disconnect the air condioning, aack re with car-
bonic snow, never with water.
1.24 Precauons on installaon
Risk of electrical shock. Instrument terminals can be connected
to dangerous voltage.
Instrument protected with double isolaon. No earth connecon
required.
Instrument conforms to CE rules and regulaons.
1.25 CE declaraon of conformity
Products DPF20
The manufacturer declares that the instruments indicated comply with the
direcves and rules indicated below.
Electromagnec compability direcve 2014/30/EU
Low voltage direcve 2014/35/EU
Direcve ROHS 2011/65/EU
Security rules EN-61010-1
Instrument Fixed
Permanently connected
Polluon degree 1 and 2 (without condensaon)
Isolaon Double
Electromagnec compability rules EN-61326-1
EM environment Industrial
Immunity levels
EN-61000-4-2 By contact ±4 KV Criteria B
By air ±8 KV Criteria B
EN-61000-4-3 Criteria A
EN-61000-4-4 On AC power lines : ±2 KV Criteria B
On DC power lines : ±2 KV Criteria B
On signal lines : ±1 KV Criteria B
EN-61000-4-5 Between AC power lines ±1 KV Criteria B
Between AC power lines and earth ±2 KV Criteria B
Between DC power lines ±1 KV Criteria B
Between DC power lines and earth ±2 KV Criteria B
Between signal lines and earth ±1 KV Criteria B
EN-61000-4-6 Criteria A
EN-61000-4-8 30 A/m at 50/60 Hz Criteria A
EN-61000-4-11 0 % 1 cycle Criteria A
40 % 10 cycles Criteria A
70 % 25 cycles Criteria B
0 % 250 cycles Criteria B
Emission levels
CISPR 11 Instrument Class A, Group 1 Criteria A
According to direcve 2012/19/EU, electronic equip-
ment must be recycled in a selecve and controlled
way at the end of its useful life.
