Omicron CMC 353 User Manual

Connections and Interfaces
31
Table 5-1:
Pin layout
Note: If using negative sequence phase rotation, swap the connectors
VOLTAGE 2 and VOLTAGE 3 as well as CURRENT 2 and CURRENT 3.
Table 5-2:
Manufacturer ordering
information
You can order the plug for generator combination socket directly from
OMICRON. For the part number refer to section 9.6, "Ordering Information"
on page 86.
Pin Signal
1- VOLTAGE N
2- VOLTAGE 3
3- VOLTAGE 2
4- VOLTAGE 1
1+ CURRENT 1
2+ CURRENT N
3+ CURRENT 3
4+ CURRENT 2
Description of the generator combination socket
Description SPEAKON LINE 8-pole
Article Number NL8FC
Manufacturer Neutrik (www.neutrik.com)
