3.1 Connectors
Figure 3-2: HGT1 connectors, top
Figure 3-3: HGT1 connectors, bottom
Figure 3-4: HGT1 connectors, left side
Figure 3-5: HGT1 connectors, right side
Not used
Voltage input
Micro SD slot
Not used
DC power socket
USB connector
Not used
Not used
