Omicron HGT1 User Manual

OMICRON 13
Hardware overview
3.2 USB connection (when using the HGT1 with PTM)
When the PTM option for the HGT1 is used, the HGT1 needs to be connected to the Window tablet
running PTM via USB.
Figure 3-6: HGT1 with USB cable and USB isolator connected
Figure 3-7: USB isolator
WARNING
Death or severe injury caused by high voltage or current possible
► Never connect the HGT1 to the tablet without using the provided USB isolator.
