MPD
800 User Manual
28
OMICRON
Figure
2-14
Typical charge setup
Use
only
the
OMICRON
24
W
DC
supply
shipped
with
RBP1
to
ch
arge
RBP1
(see
2.5
"Accessorie
s"
on
page
49). Up to five
RBP1
units can be charged in serie
s connection.
Do not charge
RBP1
in setups
requiring robust and h
igh-
sensitive meas
urements.
Figure
2-15
Charge setup with one an
d three
RBP1
devic
e
RBP1
#1
RBP1
#5
(up to 5)
Battery connection cable
Power supply
27
29
