MX2 Quick Start Guide
40 MX2 Quick Start Guide
b054 Initial freq. drop of ctrl. decel. 0 to 1000 0.01 [Hz]  1339h 0.00
b060 Maximum-limit level of window comparators O 0. to 100. (lower limit : b061 + b062 *2) (%) 1 [%]  133Fh 100
b061 Minimum-limit level of window comparators O 0. to 100. (lower limit : b060 - b062*2) (%) 1 [%]  1340h 0
b062 Hysteresis width of window comparators O 0. to 10. (lower limit : b061 - b062 / 2) (%) 1 [%]  1341h 0
b063 Maximum-limit level of window comparators OI 0. to 100. (lower limit : b064 + b066 *2) (%) 1 [%]  1342h 100
b064 Minimum-limit level of window comparators OI 0. to 100. (lower limit : b063 - b066 *2) (%) 1 [%]  1343h 0
b065 Hysteresis width of window comparators OI 0. to 10. (lower limit : b063 - b064 / 2) (%) 1 [%]  1344h 0
b070 Operation level at O disconnection 0. to 100. (%) or "no" (ignore) 1 [%]  1349h no
b071 Operation level at OI disconnection 0. to 100. (%) or "no" (ignore) 1 [%]  134Ah no
b075 Ambient temperature -10 to 50 1 [?]  134Eh 40
b078 Cumulative input power data clearance Clearance by setting "1" –  1351h 00
b079 Watt-hour display gain 1 to 1000 1  1352h 1
b082 Start frequency 10 to 999 0.01 [Hz]  1355h 0.50
b083 Carrier frequency 20 to 150 0.1 [kHz]  1356h 10.0
b084 Initialization mode (parameters or trip history) 00(disable), 01 (clearing the trip history), 02 (initializ-
ing the data), 03 (clearing the trip history and initializ-
ing the data), 04 (clearing the trip history and
initializing the data and EzSQ program)
–  1357h 00
b085 Initial value code 00 (JPN/US), 01 (EU) –  1358h 01
b086 Frequency scaling conversion factor 1 to 9999 0.01  1359h 1.00
b087 STOP key enable 00 (enabling), 01 (disabling), 02 (disabling only stop) –  135Ah 00
b088 Restart mode after FRS 0 (starting with 0 Hz), 1 (starting with matching fre-
quency), 2 (starting with active matching frequency)
-  135Bh 00
b089 Automatic carrier frequency reduction 0(disabling)/1(enabling( output current controlled))/
2(enabling( fin temperature controlled))
–  135Ch 01
b090 Dynamic braking usage ratio 0 to 1000 0.1 [%]  135Dh 0.0
b091 Stop mode selection 00 (deceleration until stop), 01 (free-run stop) –  135Eh 00
b092 Cooling fan control 01 (always operating the fan), 01 (operating the fan
only during inverter operation [including 5 minutes
after power-on ]) , 02 (operating by temperature)
–  135Fh 01
b093 Clear elapsed time of cooling fan 0(count)/1(clear) –  1360h 00
b094 Initialization target data 0 to 3 –  1361h 00
b095 Dynamic braking control 0 (disabling), 1 (enabling [disabling while the motor is
stopped]), 2 (enabling [enabling also while the motor is
stopped])
 1362h 00
b096 Dynamic braking activation level 330 to 380, 660 to 760 1. [V]  1363h 360
b097 BRD resistor value Min. Resitance to 600.0 0.1 [W]  1364h 100.0
b100 Free-setting V/f frequency (1) 0. to "free-setting V/f frequency (2)" 1 [Hz]  1367h 0
b101 Free-setting V/f voltage (1) 0. to 8000 0.1 [V]  1368h 0.0
b102 Free-setting V/f frequency (2) 0. to "free-setting V/f frequency (3)" 1 [Hz]  1369h 0
b103 Free-setting V/f voltage (2) 0. to 8000 0.1 [V]  136Ah 0.0
b104 Free-setting V/f frequency (3) 0. to "free-setting V/f frequency (4)" 1 [Hz]  136Bh 0
b105 Free-setting V/f voltage (3) 0. to 8000 0.1 [V]  136Ch 0.0
b106 Free-setting V/f frequency (4) 0. to "free-setting V/f frequency (5)" 1 [Hz]  136Dh 0
b107 Free-setting V/f voltage (4) 0. to 8000 0.1 [V]  136Eh 0.0
b108 Free-setting V/f frequency (5) 0. to "free-setting V/f frequency (6)" 1 [Hz]  136Fh 0
b109 Free-setting V/f voltage (5) 0. to 8000 0.1 [V]  1370h 0.0
b110 Free-setting V/f frequency (6) 0. to "free-setting V/f frequency (7)" 1 [Hz]  1371h 0
b111 Free-setting V/f voltage (6) 0. to 8000 0.1 [V]  1372h 0.0
b112 Free-setting V/f frequency (7) 0. to 400. 1 [Hz]  1373h 0
b113 Free-setting V/f voltage (7) 0. to 8000 0.1 [V]  1374h 0.0
b120 Brake Control Enable 00 (disabling), 01 (enabling) –  137Bh 00
b121 Brake Wait Time for Release 0 to 500 0.01 [sec.]  137Ch 0.00
b122 Brake Wait Time for Acceleration 0 to 500 0.01 [sec.]  137Dh 0.00
b123 Brake Wait Time for Stopping 0 to 500 0.01 [sec.]  137Eh 0.00
b124 Brake Wait Time for Confirmation 0 to 500 0.01 [sec.]  137Fh 0.00
b125 Brake Release Frequency 0 to 40000 0.01 [Hz]  1380h 0.00
b126 Brake Release Current 0 to 2000 0.1 [%]  1381h -
b127 Braking frequency 0 to 40000 0.01 [Hz]  1382h 0.00
b130 Deceleration overvoltage suppression enable 00 (disabling), 01 (enabling), 02 (enabling with acceler-
ation)
–  1385h 00
b131 Decel. overvolt. suppress level 200 V class: 330 to 390 (V)
400 V class: 660 to 780 (V)
1 [V]  1386h 380
b132 Decel. overvolt. suppress const. 10 to 3000 0.01 [sec.]  1387h 1.00
b133 Decel. overvolt. suppress propotional gain 0 to 500 0.01  1388h 0.20
b134 Decel. overvolt. suppress Integral time 0 to 1500 0.1 [sec.]  1389h 1.0
b145 GS input mode 00 (non Trip) /01 (Trip) –  1394h 00
b150 Display ex.operator connected 001 to 060 -  139Ah 001
b160 1st parameter of Dual Monitor 001 to 030 –  13A3h 001
b161 2nd parameter of Dual Monitor 001 to 030 –  13A4h 002
b163 Freq. set in monitoring 00 (disabling), 01 (enabling), –  13A6h 00
b164 Automatic return to the initial display 00 (disabling), 01 (enabling), –  13A7h 00
b165 Ex. operator com. loss action 00 (tripping), 01 (tripping after decelerating and stop-
ping the motor), 02 (ignoring errors), 03 (stopping the
motor after free-running), 04 (decelerating and stop-
ping the motor)
–  13A8h 02
b166 Data Read/Write select 00 (Read/Write OK), 01 (Protected) –  13A9h 00
b171 Inverter mode selection 00 (disabling), 01 (IM mode), 02 (High Freq. mode), 03
(PM mode)
–  13AEh 00
b180 Initialization trigger 00 (disabling), 01 (enabling), –  13B7h 00
Function code Function name Monitoring and setting items Units Run
mode
edit
Modbus
Register
No.
Default
