MX2 Quick Start Guide
42 MX2 Quick Start Guide
4.5 Parameter group H
C102 Reset mode selection 00 (resetting the trip when RS is on), 01 (resetting the
trip when RS is off), 02 (enabling resetting only upon
tripping [resetting when RS is on]), 03(resetting only
trip)
– 146Ah 00
C103 Restart mode after reset 00(starting with 0 Hz), 01(starting with matching fre-
quency), 02(restarting with active matching freq)
– 146Bh 00
C104 UP/DWN clear mode 00 (0Hz)/01 (EEPROM data) – 146Ch 00
C105 FM gain adjustment 50 to 200 1 [%] 146Dh 100
C106 AM gain adjustment 50 to 200 1 [%] 146Eh 100
C109 AM bias adjustment 0 to 100 1 [%] 1471h 0
C111 Overload warning level 2 0 to 2000 0.1 [%] 1473h -
C130 Output [11] on-delay time 0 to 1000 0.1 [sec.] 1486h 0.0
C131 Output [11] off-delay time 0 to 1000 0.1 [sec.] 1487h 0.0
C132 Output [12] on-delay time 0 to 1000 0.1 [sec.] 1488h 0.0
C133 Output [12] off-delay time 0 to 1000 0.1 [sec.] 1489h 0.0
C140 Output RY on-delay time 0 to 1000 0.1 [sec.] 1490h 0.0
C141 Output RY off-delay time 0 to 1000 0.1 [sec.] 1491h 0.0
C142 Logic output 1 operand A Same as the settings of C021 to C026 (except those of
LOG1 to LOG6, OPO, no)
– 1492h 00
C143 Logic output 1 operand B Same as the settings of C021 to C026 (except those of
LOG1 to LOG6, OPO, no)
– 1493h 00
C144 Logical output 1 operator 0 (AND), 1 (OR), 2 (XOR) – 1494h 00
C145 Logic output 2 operand A Same as the settings of C021 to C026 (except those of
LOG1 to LOG6, OPO, no)
– 1495h 00
C146 Logic output 2 operand B Same as the settings of C021 to C026 (except those of
LOG1 to LOG6, OPO, no)
– 1496h 00
C147 Logical output 2 operator 00 (AND), 01 (OR), 02 (XOR) – 1497h 00
C148 Logic output 3 operand A Same as the settings of C021 to C026 (except those of
LOG1 to LOG6, OPO, no)
– 1498h 00
C149 Logic output 3 operand B Same as the settings of C021 to C026 (except those of
LOG1 to LOG6, OPO, no)
– 1499h 00
C150 Logical output 3 operator 00 (AND), 01 (OR), 02 (XOR) – 149Ah 00
C160 Input [1] response time 0 to 200 - 14A4h 1
C161 Input [2] response time 0 to 200 - 14A5h 1
C162 Input [3] response time 0 to 200 - 14A6h 1
C163 Input [4] response time 0 to 200 -
14A7h 1
C164 Input [5] response time 0 to 200 - 14A8h 1
C165 Input [6] response time 0 to 200 - 14A9h 1
C166 Input [7] response time 0 to 200 - 14AAh 1
C169 Multistage speed/position determination time 0 to 200 - 14ADh 0
Function code Function name Monitoring and setting items Units Run
mode
edit
Modbus
Register
No.
Default
H001 Auto-tuning Setting 00 (disabling auto-tuning), 01 (auto-tuning without
rotation), 02 (auto-tuning with rotation)
– 1501h 00
H002 Motor data selection, 1st motor 00 (Standard motor data), 02 (auto-tuned data) – 1502h 00
H003 Motor capacity, 1st motor 00(0.1kW)- 15 (18.5kW) – 1503h -
H004 Motor poles setting, 1st motor 0 (2 poles), 1 (4 poles), 2 (6 poles),3 (8 poles), 4 (10) – 1504h 4P
H005 Motor speed constant, 1st motor 1 to 1000 1[%] 1506h 100
H006 Motor stabilization constant, 1st motor 0 to 255 1 1507h 100
H020 Motor constant R1, 1st motor 1 to 65530 0.001 [] 1516h -
H021 Motor constant R2, 1st motor 1 to 65530 0.001 [] 1518h -
H022 Motor constant L, 1st motor 1 to 65530 0.01 mH 151Ah -
H023 Motor constant Io 1 to 65530 0.01 [A] 151Ch -
H024(32-bits) Motor constant J 1 to 9999000 0.001 151Dh -
151Eh
H030 Auto constant R1, 1st motor 1 to 65530 0.001 [] 1525h -
H031 Auto constant R2, 1st motor 1 to 65530 0.001 [] 1527h -
H032 Auto constant L, 1st motor 1 to 65530 0.01 mH 1529h -
H033 Auto constant Io, 1st motor 1 to 65530 0.01 [A] 152Bh -
H024(32-bits) Auto constant J, 1st motor 1 to 9999000 0.001 152Ch -
152Dh
H050 Slip compensation P gain for V/f control with FB 0 to 10000 0.1 153Dh 0.20
H051 Slip compensation P gain for V/f control with FB 0 to 10000 1 153Eh 2
H102 PM motor code setting 00 (Standard motor data), 01(auto-tuned data) – 1571h 00
H103 PM motor capacity 0.1/0.2/0.4/0.55/0.75/1.1/1.5/2.2/3.0/3.7/4.0/5.5/7.5/
11.0/15.0/18.5
– 1572h -
H104 PM motor poles setting 2(0)/4(1)/6(2)/8(3)/10(4)/12(5)/14(6)/16(7)/18(8)/
20(9)/22(10)/24(11)/26(12)/28(13)/30(14)/32(15)/
34(16)/36(17)/38(18)/40(19)/42(20)/44(21)/46(22)/
48(34) pole
– 1573h 4P
Function code Function name Monitoring and setting items Units Run
mode
edit
Modbus
Register
No.
Default
