4 Maintenance and inspection
4-4 Replacing the battery
BU5002R/BU3002R/BU3002RH
105
4
BU3002R, BU3002RH
1.
Loosen the 4 screws () on the front panel of the UPS, and remove the front
panel ().


2.
Press the clip that locks the battery connector (), and pull off the connector
while holding the battery connector ().

