2 Installation and connection
2-2 Installation
BU5002R/BU3002R/BU3002RH
32
2 2-1 Rackmount installation (EIA/JIS 19-inch rack, server rack)
Warning
When installing onto a rack, be sure to use the provided support
angles to support and fix this product.
⚫ Support each unit individually with support angles.
⚫ When installing onto a rack, be sure to use both the support angles and
ear brackets provided with this product. The ear brackets alone cannot
support this product without the support angles.
⚫ The mass of each unit is about 57 kg for the BU5002R, about 31 kg for
the BU3002R, and about 30 kg for the BU3002RH.
⚫ There is a risk that an injury could be caused if the unit falls.
Caution
When installing this unit on a rack, install this unit on the
lowermost shelf of the rack. However, when installing an
expansion battery unit, place it on the lower shelf instead.
⚫ You may be injured if the product is dropped.
Be sure to use the mounting screws provided with this product.
⚫ If long screws not provided with this product are used for installation of
the case, there is a risk of internal damage.
⚫ If screws not provided with this product are used, the structural strength
may become insufficient, and it may lead to an accident such as falling of
this unit.
■ Items in the package used when installing in a 19 inch rack
Support angle (L) ................................... 1
Support angle (R) ................................... 1
Ear bracket ............................................. 2
Ear bracket mounting
flat-head screws (M3) ............................. 8
Fixing screws for EIA/JIS rack (M5) ...... 12
Fixing flat-head screws
for JIS rack (M5) ............................. 2
Mounting nuts for EIA rack (M5) ... 12
