Reference documents
A. Specifications
BU5002R/BU3002R/BU3002RH
128
Model number
BU5002R
BU3002R
BU3002RH
AC
output
Number of phases
Single phase 2 wires
Output receptacle
(backup)
NEMA L6-30R × 2/terminal
block
C19 (female) × 2,
C13 (female) × 8
Terminal block
Battery
Expected life of sealed
lead battery
5 years (long life) *7
Battery capacity
(V/Ah)/number
12 VDC/8.5 Ah/12 pcs
12 VDC/8.5 Ah/6 pcs
Expansion
○ (BUM5002R) Up to 3
units
○ (BUM3002R) Up to 3 units
Charging time
90% charge without any expansion battery units: 8 hours max., full charge
without any expansion battery units: 12 hours max.
Charging time with
battery expansion
1 expansion battery unit: 24 hours/90%, 32 hours/full charge
2 expansion battery units: 40 hours/90%, 52 hours/ full charge
3 expansion battery units: 56 hours/90%, 72 hours/full charge
Backup time
5 min (4500 W) *8
4.5 min (2700 W) *8
External dimensions
(W × D × H mm)
430×700×130.5 (3U)
430×660×86 (2U)
Mass of the main unit
About 57 kg
About 31 kg
About 30 kg
Operating environmental
temperature/humidity
0 to 40°C/25 to 85% RH (no condensation)
Storage environmental
temperature/humidity
-15 to 50°C/10 to 90% RH (battery fully charged, storage under no condensation)
Noise regulations
Complies with VCCI class A
Safety standard
UL 1778 certified
Internal power consumption *9
Without load normal/maximum
With rated load
normal/maximum
55 W/225 W
35 W/120 W
35 W/120 W
345 W/520 W
225 W/310 W
225 W/310 W
Noise
50 dB or less (during normal operation), 55 dB or less (during backup operation)
Cooling method
(with/without fan)
Forced cooling (with fan)
Serial communication (RS-232C)
(interface shape)
● (D-sub 9pin)
*1 Input voltage range that can start the UPS by turning the power switch ON.
*2 The value is changed as follows depending on the load capacity.
100V+1.0857x(load capacity%-40%)V to 288 V±3 V (with 40% or more connection load)
100V to 288 V±3 V (with smaller than 40% connection load)
*3 Input voltage range in which normal operation is enabled.
*4 The value is changed as follows depending on the start-up voltage.
(Minimum start-up voltage)+10V to 278 V±3 V
*5 When the rated load is connected.
*6 When the UPS is used with the standard AC input plug as a conforming product of UL
standards, use in 4660 VA/4200 W or less.
*7 When the ambient temperature is 25°C.
*8 When the ambient temperature is 25°C and the battery is in its initial state.
*9 At the rated input voltage. To convert into heat value (kJ/h), calculate using the following
formula: Internal power consumption (W) x 3.6.
● Indicates a standard feature
○ Indicates an optional feature
