4 Data Exchange with the CPU Unit
4-24
CJ-series PROFIBUS Master Unit Operation Manual for NJ-series CPU Unit (W509)
The Slave New Diagnostics flags indicate for each slave device that it sent a new diagnostics message
to the PROFIBUS Master Unit since the last time it was read or cleared by the NJ-series controller unit.
An Array data type is used to access individual slave diagnostic status with the Device Variable
*_SlvNewDiag.
The flags are also allocated to a block of eight CIO words and each bit in the block corresponds to a
device address. The flags are allocated to a block of eight CIO words and each bit in the block corre-
sponds to a device address.
Bits 00 to 63 of LWORD-type *_SlvNewDiagL and bits 0 to 61 of LWORD-type *_SlvNewDiagH Device
Variable for CJ-series Unit correspond to slaves at node addresses.
4-2-9 Slave New Diagnostics Flags (*_SlvNewDiagL, *_SlvNewDiagH,
*_SlvNewDiag)
1514131211109876543210
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
*_SlvNewDiagL
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
*_SlvNewDiagL
47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32
*_SlvNewDiagL
63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48
*_SlvNewDiagL
79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64
*_SlvNewDiagH
95 94 93 92 91 90 89 88 87 86 85 84 83 82 81 80
*_SlvNewDiagH
111 110 109 108 107 106 105 104 103 102 101 100 99 98 97 96
*_SlvNewDiagH
125 124 123 122 121 120 119 118 117 116 115 114 113 112
*_SlvNewDiagH
Slave station 00 to 15
Slave station 16 to 31
Slave station 32 to 47
Slave station 48 to 63
Slave station 64 to 79
Slave station 80 to 95
Slave station 96 to 111
Slave station 112 to 125
To Next Page
