Introduction
6
CJ-series PROFIBUS Master Unit Operation Manual for NJ-series CPU Unit (W509)
SmartSlice GRT1-Series Slice I/O Units Operation Manual (Cat. No.
W455)
Section Description
Section 1
Available Units and Features
This section describes the features of GRT1-series Slice I/O Units and lists the avail-
able Units.
Section 2
Shared Specifications and Func-
tions
This section describes the specifications and functions that are shared by all of the
Slice I/O Units.
Section 3
Installation and Wiring
This section provides information on installing and wiring the Slice I/O Units.
Section 4
Digital I/O Units
This section provides the specifications and shows the components, terminal
arrangements, wiring diagrams and dimensions for the Digital I/O Units.
Section 5
Analog I/O Units
This section provides the information required to operate Analog Input Units and
Analog Output Units.
Section 6
Temperature Input Units
This section provides the information required to operate Temperature Input Units.
Section 7
Counter Units and Positioning Unit
This section provides the information required to operate Counter Units and the Posi-
tioning Unit.
Section 8
Other Units
This section provides the basic specifications for the other Units used in Slice I/O ter-
minals.
Section 9
Troubleshooting
This section describes error processing and troubleshooting procedures needed to
keep the Slice I/O Units operating properly.
Appendices
The appendices describe the following:
Explicit Messages
Standard Models
Power Consumption and Weight Tables
I/O Current Consumption Table
Precautions When Connecting Two-wire DC Sensors
