About this Manual:
This manual describes the function blocks and related functionality of the CX-Programmer Ver. 5.0
used together with CS1-H, CJ1-H, and CJ1M CPU Units with unit version 3.0 or later, and includes the
sections described on the next page. The CX-Programmer Ver. 5.0 is software that enables the per-
sonal computer to be used as a function block programming device, and can be used only for SYS-
MAC CS-series and CJ-series CPU Units that support function blocks.
The CX-Programmer Ver. 5.0 function block functions have been enhanced. This manual describes
only CX-Programmer Ver. 5.0 operations that are related to functions blocks. For operations not related
to function blocks, refer to the CX-Programmer Operation Manual (enclosed, Cat. No. W437). This
manual also provides only information related to function blocks for the CS1-H, CJ1-H, and CJ1M CPU
Units. For other information, refer to the CS/CJ-series manuals.
Please read this manual and related manuals carefully and be sure you understand the information
provided before attempting to install or operate the CX-Programmer Ver. 5.0 or the CS1-H, CJ1-H, or
CJ1M CPU Units. Be sure to read the precautions provided in the following section.
Manuals Related to the CX-Programmer Ver. 5.0
Manuals Related to the CS1-H, CJ1-H, CJ1M CPU Units
Name Cat. No. Contents
SYSMAC WS02-CXPC1-E-V50
CX-Programmer Ver. 5.0 Operation Manual
Function Blocks
(CS1G-CPU
@@H, CS1H-CPU@@H,
CJ1G-CPU@@H, CJ1H-CPU@@H,
CJ1M-CPU
@@ CPU Units)
W438 Describes the functionality unique to the CX-Programmer Ver.
5.0 and CS/CJ-series CPU Units with unit version 3.0 or later
based on function blocks. Functionality that is the same as
that of the CX-Programmer is described in W437 (enclosed).
SYSMAC WS02-CXPC1-E-V50
CX-Programmer Operation Manual
W437 Provides information on how to use the CX-Programmer for
all functionality except for function blocks.
Name Cat. No. Contents
SYSMAC CS Series
CS1G/H-CPU@@-EV1, CS1G/H-CPU@@H
Programmable Controllers
Operation Manual
W339 Provides an outline of and describes the design, installation,
maintenance, and other basic operations for the CS-series
PLCs.
The following information is included:
An overview and features
The system configuration
Installation and wiring
I/O memory allocation
Troubleshooting
Use this manual together with the W394.
SYSMAC CJ Series
CJ1G-CPU@@, CJ1G/H-CPU@@H, CJ1G-
CPU@@P, C J 1 M - C P U @@
Programmable Controllers
Operation Manual
W393 Provides an outline of and describes the design, installation,
maintenance, and other basic operations for the CJ-series
PLCs.
The following information is included:
An overview and features
The system configuration
Installation and wiring
I/O memory allocation
Troubleshooting
Use this manual together with the W394.
