Instruction Support and Operand Restrictions Section 2-6
2-6-3 Sequence Control Instructions
Instruction Mnemonic Function
code
Symbol Operands Supported
variable
data types
AT setting or
array variable
required
(Required
word data
size shown in
parentheses.)
END END 001 --- --- ---
NO OPERATION NOP 000 --- --- --- ---
INTERLOCK IL 002 --- --- ---
INTERLOCK
CLEAR
ILC 003 --- --- ---
MULTI-INTER-
LOCK DIFFER-
ENTIATION
HOLD
MILH 517 N: Interlock number # + decimal
only
---
D: Interlock Status
Bit
BOOL ---
MULTI-INTER-
LOCK DIFFER-
ENTIATION
RELEASE
MILR 518 N: Interlock number # + decimal
only
---
D: Interlock Status
Bit
BOOL ---
MULTI-INTER-
LOCK CLEAR
MILC 519 N: Interlock number # + decimal
only
---
JUMP JMP 004 Not supported in function
blocks
N: Jump number --- ---
JUMP END JME 005 Not supported in function
blocks
N: Jump number --- ---
CONDITIONAL
JUMP
CJP 510 Not supported in function
blocks
N: Jump number --- ---
CONDITIONAL
JUMP
CJPN 511 Not supported in function
blocks
N: Jump number --- ---
MULTIPLE
JUMP
JMP0 515 --- --- ---
MULTIPLE
JUMP END
JME0 516 --- --- ---
FOR-NEXT
LOOPS
FOR 512 N: Number of loops UINT ---
BREAK LOOP BREAK 514 --- --- ---
FOR-NEXT
LOOPS
NEXT 513 --- --- ---
END
IL
ILC
MILH
N
D
MILR
N
D
MILC
N
JMP0
JME0
FOR
N
BREAK
NEXT
