Omron CX-PROGRAMMER 5.0-FUNCTION BLOCK OPERATION User Manual

55
Instruction Support and Operand Restrictions Section 2-6
2-6-2 Sequence Output Instructions
BIT TEST AND TST 350 S: Source word WORD ---
N: Bit number UINT ---
BIT TEST AND TSTN 351 S: Source word WORD ---
N: Bit number UINT ---
BIT TEST OR TST 350 S: Source word WORD ---
N: Bit number UINT ---
BIT TEST OR TSTN 351 S: Source word WORD ---
N: Bit number UINT ---
Instruction Mnemonic Function
code
Symbol Operands Supported
variable
data types
AT setting or
array variable
required
(Required
word data size
shown in
parentheses.)
OUTPUT OUT
!OUT
--- BOOL ---
OUTPUT NOT OUT NOT
!OUT NOT
--- BOOL ---
KEEP KEEP
!KEEP
011 --- BOOL ---
DIFFERENTI-
ATE UP
DIFU
!DIFU
013 --- BOOL ---
DIFFERENTI-
ATE DOWN
DIFD
!DIFD
014 --- BOOL ---
Instruction Mnemonic Function
code
Symbol Operands Supported
variable
data types
AT setting or
array variable
required
(Required word
data size
shown in
parentheses.)
AND TST
S
N
AND TSTN
S
N
TST
S
N
TSTN
S
N
KEEP
B
S (Set)
R (Reset)
DIFU
B
DIFD
B
