Omron CX-PROGRAMMER 5.0-FUNCTION BLOCK OPERATION User Manual

54
Instruction Support and Operand Restrictions Section 2-6
AND NOT AND NOT
!AND NOT
@AND NOT
%AND NOT
!@AND NOT
!%AND NOT
--- BOOL ---
OR OR
@OR
%OR
!OR
!@OR
!%OR
--- BOOL ---
OR NOT OR NOT
!OR NOT
@OR NOT
%OR NOT
!@OR NOT
!%OR NOT
--- BOOL ---
AND LOAD AND LD --- --- ---
OR LOAD OR LD --- --- ---
NOT NOT 520 --- --- ---
CONDITION
ON
UP 521 --- --- ---
CONDITION
OFF
DOWN 522 --- --- ---
BIT TEST LD TST 350 S: Source word WORD ---
N: Bit number UINT ---
BIT TEST LD TSTN 351 S: Source word WORD ---
N: Bit number UINT ---
Instruction Mnemonic Function
code
Symbol Operands Supported
variable
data types
AT setting or
array variable
required
(Required word
data size
shown in
parentheses.)
Bus bar
Bus bar
Logic block Logic block
Logic block
Logic block
NOT
UP
DOWN
TST
S
N
TSTN
S
N
