Instruction Support and Operand Restrictions Section 2-6
DOUBLE SIGNED
BINARY DIVIDE
/L
@/L
431 Dd: 1st dividend
word
DINT ---
Dr: 1st divisor word DINT ---
R: 1st result word LWORD Yes (2)
DINT must
be used
when
array vari-
ables are
required.
UNSIGNED
BINARY DIVIDE
/U
@/U
432 Dd: Dividend word UINT ---
Dr: Divisor word UINT ---
R: Result word DWORD Yes (2)
UINT must
be used
when
array vari-
ables are
required.
DOUBLE
UNSIGNED
BINARY DIVIDE
/UL
@/UL
433 Dd: 1st dividend
word
UDINT ---
Dr: 1st divisor word UDINT ---
R: 1st result word LWORD Yes (2)
UDINT
must be
used
when
array vari-
ables are
required.
BCD DIVIDE /B
@/B
434 Dd: Dividend word WORD ---
Dr: Divisor word WORD ---
R: Result word DWORD Yes (2)
WORD
must be
used
when
array vari-
ables are
required.
Instruction Mnemonic Function
code
Symbol Operands Supported
variable
data types
AT
setting or
array
variable
required
(Required
word data
size
shown in
parenthe-
ses.)
/L
Dd
Dr
R
/U
Dd
Dr
R
/UL
Dd
Dr
R
/B
Dd
Dr
R
