262
Advanced Function Setting Level Section 5-10
• This parameter sets the function to be assigned to control output 2.
Note (1) If c-o is assigned for standard control, a value equivalent to 0% will be
output.
(2) Can be selected for a relay output, voltage output (for driving SSR), or
SSR output only.
(3) The setting will be ignored when the Program Pattern parameter is set to
OFF.
(4) WR1 to WR8 are not displayed when the logic operation function is not
used.
(5) If the Standard or Heating/Cooling parameter is set to heating/cooling
control, control automatically switches to c-o.
â– Related Parameters
Standard or heating/cooling: Page 228, Program pattern: Page 229, (initial
setting level)
out2 Control Output 2 Assignment
There must a transfer output, or if
there is no transfer output, control
output 1 must be a linear output or
control output 2 must not be a linear
output. If control output 1 is not a lin-
ear output and control output 2 is a
linear output, the transfer output type
must be set to OFF.
Setting range Default
none: No function is assigned to control output 2. none
(See note
5.)
o: Heating control output is output.
c-o: Cooling control output is output. (See note 1.)
alm1: Alarm 1 is output. (See note 2.)
alm2: Alarm 2 is output. (See note 2.)
alm3: Alarm 3 is output. (See note 2.)
p.end: Program end is output. (See notes 2 and 3.)
ralm: Control output ON/OFF count alarm (See note 2.)
wr1: Work bit 1 (See notes 2 and 4.)
wr2: Work bit 2 (See notes 2 and 4.)
wr3: Work bit 3 (See notes 2 and 4.)
wr4: Work bit 4 (See notes 2 and 4.)
wr5: Work bit 5 (See notes 2 and 4.)
wr6: Work bit 6 (See notes 2 and 4.)
wr7: Work bit 7 (See notes 2 and 4.)
wr8: Work bit 8 (See notes 2 and 4.)
Function
Setting
See
See
To Next Page
