Advanced Function Setting Level Section 5-10

• This parameter sets the function to be assigned to control output 1.

Note (1) If c-o is assigned for standard control, a value equivalent to 0% is output.

(2) Can be selected for a relay output, voltage output (for driving SSR), or

SSR output only.

(3) Can be selected when the Program Pattern parameter is set to OFF, but

the function will be disabled.

(4) WR1 to WR8 are not displayed when the logic operation function is not

used.

■ Related Parameters

Standard or heating/cooling: Page 228, Program pattern: Page 229, Transfer

output type: Page 235 (initial setting level)

out1 Control Output 1 Assignment

There must a transfer output, or if

there is no transfer output, control

output 1 must not be a linear output

or if it is a linear output, the transfer

output type must be set to OFF.

Setting range Default

None: No function is assigned to control output 1. o

o: Heating control output is output.

c-o: Cooling control output is output. (See note 1.)

alm1: Alarm 1 is output. (See note 2.)

alm2: Alarm 2 is output. (See note 2.)

alm3: Alarm 3 is output. (See note 2.)

p.end: Program end is output. (See notes 2 and 3.)

ralm: Control output ON/OFF count alarm (See note 2.)

wr1: Work bit 1 (See notes 2 and 4.)

wr2: Work bit 2 (See notes 2 and 4.)

wr3: Work bit 3 (See notes 2 and 4.)

wr4: Work bit 4 (See notes 2 and 4.)

wr5: Work bit 5 (See notes 2 and 4.)

wr6: Work bit 6 (See notes 2 and 4.)

wr7: Work bit 7 (See notes 2 and 4.)

wr8: Work bit 8 (See notes 2 and 4.)

Function

Setting

See
