Omron E5AN-H

319
Appendix
Scaling Upper Limit in-h Scaling lower limit + 1 to
32400
100 None
Scaling Lower Limit in-l −19,999 to scaling upper limit
−1
0None
Decimal Point dp 0 to 3 0 None
Temperature Unit d-u °C, °F c, f °CNone
SP Upper Limit sl-h Temperature input: SP lower
limit + 1 to input range upper
limit
1300.0 EU
Analog input: SP lower limit +
1 to Scaling upper limit
SP Lower Limit sl-l Temperature input: Input
range lower limit to SP upper
limit −1
−200.0 EU
Analog: Scaling lower limit to
SP upper limit −1
PID ON/OFF cntl ON/OFF 2-PID onof, pid PID None
Standard or Heating/
Cooling
s-hc Standard or heating/cooling send, h-c Standard None
ST st OFF, ON off, on ON None
Program Pattern ptrn OFF, STOP, CONT, LOOP off, stop,
cont
OFF None
Valid Program Bank pbnk 0 to 7 7 None
Control Period
(Heating)
cp 0.5 or 1 to 99 0.5, 1 to 99 20 Second
Control Period (Cool-
ing)
c-cp 0.5 or 1 to 99 0.5, 1 to 99 20 Second
Direct/Reverse
Operation
orev Reverse operation, direct
operation
or-r, or-d Reverse
operation
None
Parameters Characters Setting (monitor) value Display Default Unit Set value
