Omron E5AN-H User Manual

320
Appendix
Alarm 1Type alt1 0: Alarm function OFF
1: Upper and lower-limit
alarm
2: Upper-limit alarm
3: Lower-limit alarm
4: Upper and lower-limit
range alarm
5: Upper and lower-limit
alarm with standby
sequence
6: Upper-limit alarm with
standby sequence
7: Lower-limit alarm with
standby sequence
8: Absolute-value upper-limit
alarm
9: Absolute-value lower-limit
alarm
10: Absolute-value upper-limit
alarm with standby
sequence
11: Absolute-value lower-limit
alarm with standby
sequence
12: LBA (Loop Burnout Alarm)
13: PV change rate alarm
14: Remote SP absolute
value upper limit alarm
(See note 1.)
15: Remote SP absolute
value lower limit alarm
(See note 1.)
2None
Alarm 1 Hysteresis alh1 Temperature input: 0.1 to
3240.0
0.2 °C or °F
Analog input: 0.01 to 99.99 0.02 %FS
Alarm 2 Type alt2 Same settings as the alarm 1
type.
Note The 12: LBA (Loop
Burnout Alarm) setting
cannot be used.
2None
Alarm 2 Hysteresis alh2 Temperature input: 0.1 to
3240.0
0.2 °C or °F
Analog input: 0.01 to 99.99 0.02 %FS
Alarm 3 Type alt3 Same settings as the alarm 2
type
2None
Alarm 3 Hysteresis alh3 Temperature input: 0.1 to
3240.0
0.2 °C or °F
Analog input: 0.01 to 99.99 0.02 %FS
Transfer Output Type tr-t OFF: OFF
SP: Set point (See note 2.)
SP-M: Ramp set point
PV: Process value
MV: Manipulated variable
(heating) (See note 3.)
C-MV: Manipulated variable
(cooling) (See note 4.)
V-M: Valve Opening (See
note 5.)
off
sp
sp-m
pv
mv
c-mv
v-m
OFF None
Transfer Output
Upper Limit
tr-h See note 6. See note 6. See note 6.
Parameters Characters Setting (monitor) value Display Default Unit Set value
