105
Advanced Function Setting Level Section 5-6
This parameter returns parameter settings to their defaults.
ON: Initializes all parameters.
OFF: Turns the E5AZ/E5EZ OFF after returning parameter settings to their
defaults.
“Multi-SP” is a function for setting set points 0 to 3 in advance, and selecting
these set points by a combination of event inputs 1 and 2.
The “number of multi-SP uses” parameter is used when the number of preset
set points is 2 or 4. This parameter determines display or non-display of the
“event input assignment 1” and “event input assignment 2” parameters.
The “number of multi-SP uses” displays which functions are assigned to event
inputs 1 and 2.
Note “STOP (RUN/STOP) switching” can be set only on one of event in-
put assignments 1 or 2. The event input on the side that is set can
be used. The setting on the other side becomes “NONE”.
• Default: 1
Multi-SP can be used when the option event input unit E53-AZB is
mounted on the E5AZ/E5EZ, and the “number of multi-SP uses” is set to
“1” or “2”.
• When the number of multi-SP uses is set to “1”
Parameter Initialization
Function
Setting
Number of Multi-SP
Uses
The option event input unit E53-AZB
must be mounted in the E5AZ/E5EZ.
Number
of
Multi-SP
Uses
Setting Event Input Function
Event input
assignment 1
Event input
assignment 2
Event input 1
function
Event input 2
function
0 NONE or STOP (See note.) NONE or RUN/STOP switching
(See note.)
1 – (not displayed) NONE or STOP Multi–SP 2 set
points (set point 0/1
switching)
NONE or
RUN/STOP switch-
ing
2 – (not displayed) Multi–SP 4 set points
(set point 0/1/2/3 switching)
Event input 1 Selected Set Point
OFF Set point 0
ON Set point 1
Function
Setting
