Advanced Function Setting Level Section 5-6
• Sets the time constant of the input digital filter. The following figure shows
the effect on data after passing through the digital filter:
• This parameter adds the facility of displaying only the PV. It is added to
the top of the operation level. It is used to give the option of displaying the
PV and SP or just the PV only.
Input digital filter
Setting Range
Unit Default
0.0 to 999.9 Second 0.0
Function
Time
PV before passing through filter
PV after passing through filte
Time
constant
Input digital filter
A
0.63A
Setting
Additional PV display
pVad
Setting Range
Default
on: Displayed / off: Not displayed off
Function
Setting
