3 Click Yes.
The selected image is deleted.
6-6-5
Loading Images
A registered image can be loaded as a measurement image.
1 In the Main window, select and click Tool → Registered Image Manager.
Registered image dialog box is displayed.
2
Select the image to load and click Save.
Icon Function Description
Save Saves the image in the displayed registration destination
folder (sub-folder) to the specified folder. Specifying the des-
tination folder is done via the displayed folder selection dia-
log box.
3 The selected image is loaded into the selected folder.
6 Performing Measurement and Adjustment
6 - 42
FH/FHV Series Vision System User’s Manual (Z365-E1)

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
