Omron fh series User Manual

10-8
Extending the Functions in a Meas-
urement Flow or Scene [Scene Con-
trol Macro Tool]
This function can not be used with the FHV series.
Using this tool, can complement or extend the operation of measurement flow or Scene.
This tool is useful when the following cases:
• When add the processing unit and measurement flow.
• When the manage data common in the multiple processing units.
For details, refer to Description of the Setting Screen of the Scene Control Macro Tool and How to
Configure Settings in the Vision System FH Series Macro Customize Functions Programming Manual
(Cat. No. Z367).
10 Advanced Usage
10 - 51
FH/FHV Series Vision System User’s Manual (Z365-E1)
10-8 Extending the Functions in a Measurement
Flow or Scene [Scene Control Macro Tool]
10

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
