3-3
Checking System Information [Sys-
tem Information]
The Controller model and measurement application version can be checked.
You can check the external storage status only on the FH series and the FHV series.
Refer to 9-1-3 Using External Storage Devices on page 9 - 5.
Additionally, you can use a Firmware upgrade tool.
Refer to 3-8 Updating Measurement Application [Version-up] on page 3 - 38.
1 In the Main Window, select System information from the Function menu.
The System information dialog box is displayed.
2 The following information can be checked.
Sensor Controller model, Version of measurement application, OS version of Sensor Control-
ler.
Additional Information
When executed from the Remote Operation Tool, you can check the information of both the
controller and the remote operation tool.
3 Basic Operations
3 - 24
FH/FHV Series Vision System User’s Manual (Z365-E1)
