5-4
Displaying and Checking Processing
Branches in a Scene
To see how a branch affects the processing flow after you edit a scene in the edit flow window, start
the Flow Viewer. Select Flow Viewer from the Tool menu.
5-4-1
Overview [Flow Viewer]
The Flow Viewer shows the flow of processing for the measurement flow that is currently being edited.
This makes it easy to understand the relationship of branches and folders in the measurement flow.
The Flow Viewer allows you to edit the measurement flow, and also allows you to edit, rename, and
save processing units in the same way as with the edit flow window.
You can save the flow of processing for the currently displayed measurement flow as an image file.
In Edit Flow Window In Flow Viewer
5-4-2
Window Configuration [Flow Viewer]
The window configuration for the Flow Viewer is shown below.
5 Creating Measurement Scenes
5 - 10
FH/FHV Series Vision System User’s Manual (Z365-E1)

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
