Section 1 OUTLINE
1-10
OUTLINE
■ Dedicated Absolute Encoder
■ Accessories (Order Separately)
* Ask your OMRON representative about the availability of non-standard lengths.
● Recommended USB Cables
Note: If you cannot purchase the recommended replacement cable, purchase a commercially available
USB cable with a ferrite core attached to it.
Type Resolution Cable length Model
Economy 256 2 m E6CP-AG5C-C 256P/R 2M
Standard 256 1 m E6C3-AG5C-C 256P/R 1M
2 m E6C3-AG5C-C 256P/R 2M
360 E6C3-AG5C-C 360P/R 2M
720 E6C3-AG5C-C 720P/R 2M
Rigid 256 2 m E6F-AG5C-C 256P/R 2M
360 E6F-AG5C-C 360P/R 2M
720 E6F-AG5C-C 720P/R 2M
Name Specifications Model
Discrete Wire Output Cable 2 m Y92S-41-200
Connector-type Output Cable 2 m E5ZE-CBL200
Support Software CD-ROM H8PS-SOFT-V1
Shaft Coupling for the E6CP Axis: 6 mm dia. E69-C06B
Shaft Coupling for the E6C3 Axis: 8 mm dia. E69-C08B
Shaft Coupling for the E6F Axis: 10 mm dia. E69-C10B
Extension Cable (*) 5 m (same for E6CP, E6C3, and E6F) E69-DF5
Parallel Input Adapter Two Units can operate in parallel. Y92C-30
Protective Cover --- Y92A-96B
Watertight Cover --- Y92A-96N
Track Mounting Base --- Y92F-91
Mounting Track 50 cm × 7.3 mm (l × t) PFP-50N
1 m × 7.3 mm (l × t) PFP-100N
1 m × 16 mm (l × t) PFP-100N2
End Plate --- PFP-M
Spacer --- PFP-S
Name Recommended manufacturer Specifications Model
USB Cable ELECOM CO. Ltd. A-mini B, 2 m U2C-MF20BK
