Section 2 INSTALLATION
2-14
INSTALLATION
2.2.3 Encoder Connecting Direction
Encoder
Output cable
Encoder
Encoder
Output cable
Encoder
H8P
S
-8B H8P
S
-8BF
H8PS-16B
H8PS-32B
H8PS-16BF
H8PS-32BF
