Omron H8PS User Manual

Section 2 INSTALLATION
2-16
INSTALLATION
■ E6C3-AG5C-C
* Order coupling E69-C08B separately.
• Dimensions
• Bracket Mounting Diagram
Hirose Electric:
RP13A-12PD-13SC
Round, shielded vinyl-insulated cord with 12 cores (oil-resistant)
(external dia.: 6, cross-sectional area: 0.2 mm
2
, insulation: 1.1 mm dia.),
standard length: 1 m
6
8.8
6
50 dia.
1
5
D cut: Z-phase position (error ±15°)
10
40±0.1 dia.
10
Three, M4 holes
(depth: 5)
120°±0.1
120° ±0.1
(15)
38
20
(58)
37
8 dia.
+0
−0.018
30 dia.
+0
−0.021
1
