2.3 Mounting (Encoder)
2-21
INSTALLATION
● Mounting Procedure
1. Insert the shaft into the Coupling.
4. Connect the power and I/O lines.
5. Turn ON the power and check the outputs.
2. Secure the Encoder.
3. Secure the Coupling.
Refer to the table for
the maximum
insertion lengths of
the shaft into the
Coupling.
Do not secure the Coupling and
shaft with screws at this time.
Be sure to turn OFF the Encoder
before connecting the lines.
Coupling Tightening torque
E69-C06B 0.25 N·m
E69-C08B 0.44 N·m
E69-C10B 0.44 N·m
Coupling
Maximum insertion
length
E69-C06B 5.5 mm
E69-C08B 6.8 mm
E69-C10B 7.1 mm
