4-1
HOW TO USE THE
ADVANCED FUNCTIONS
Section 4 HOW TO USE THE
ADVANCED
FUNCTIONS
The basic operation of the H8PS Cam Positioner can be mastered by following the expla-
nations in Section 3.
Section 4 deals with the functions that make operation easier, and the advanced
functions.
The functions explained in this section can be really advantageous depending on the
application. Please read about these functions and become familiar with them so that you
can use the appropriate functions for efficient operation.
4.1 Mode Transitions................................................................4-2
4.2 Advance Angle Compensation (ADV) Function .................4-4
4.3 Prohibiting Outputs .......................................................... 4-11
4.4 Pulse Output (F1/F2) .......................................................4-12
4.5 Speed Alarm (F3/F4).......................................................4-15
4.6 Step Number Limit (F5) ...................................................4-20
4.7 Cam Protection (F6) ........................................................ 4-23
4.8 Bank Function (F7/F8/F9)................................................4-24
4.9 E24 Detection Enable/Disable (F10) ...............................4-32
