Omron K3MA-J User Manual

A-4
APPENDIX
Input Characteristics
K3MA-J
K3MA-L
K3MA-F
Input type Setting range Control range Measuring accuracy
0-20 0 to 20mA -2 to 22mA
±0.1%FS±1digit max. at 23°C±3°C
4-20 4 to 20mA 2 to 22mA
0-5 0 to 5V -0.5 to 5,5V
1-5 1 to 5V 0.5 to 5.5V
5±5V±5.5V
±0.1%FS±1digit max. at 23°C±5°C
10 ±10V ±11V
Input type
Set
value
Setting range Control range Indication accuracy
Platinum resistance
thermometer
Pt100
0
-200 to 850°C
-300 to 1500°F
-220 to 870°C
-340 to 1540°F
±0.5% of indicated value or ±1°C, whichever is larger
±1digit max.
1
-199.9 to 500.0°C
-199.9 to 900.0°F
-199.9 to 520.0°C
-199.9 to 940.0°F
2
0.0 to 100.0°C
0.0 to 210.0°F
-20.0 to 120.0°C
-40.0 to 250.0°F
JPt100
3
-199.9 to 500.0°C
-199.9 to 900.0°F
-199.9 to 520.0°C
-199.9 to 940.0°F
4
0.0 to 100.0°C
0.0 to 210.0°F
-20.0 to 120.0°C
-40.0 to 250.0°F
Thermocouple
K
5
-200 to 1300°C
-300 to 2300°F
-220 to 1320°C
-340 to 2340°F
±0.5% of indicated value or ±1°C, whichever is larger
±1digit max.
(at a temperature of -100°C or less: ±2°C±1digit max.)
6
-20.0 to 500.0°C
0.0 to 900.0°F
-40.0 to 520.0°C
-40.0 to 940.0°F
±0.5% of indicated value or ±1°C, whichever is larger
±1digit max.
J
7
-100 to 850°C
-100 to 1500°F
-120 to 870°C
-140 to 1540°F
8
-20.0 to 400.0°C
0.0 to 750.0°F
-40.0 to 420.0°C
-40.0 to 790.0°F
T
9
-200 to 400°C
-300 to 700°F
-220 to 420°C
-340 to 740°F
±0.5% of indicated value or ±1°C, whichever is larger
±1digit max.
(at a temperature of -100°C or less: ±2°C±1digit max.)
10
-199.9 to 400.0°C
-199.9 to 700.0°F
-199.9 to 420.0°C
-199.9 to 740.0°F
E11
0 to 600°C
0 to 1100°F
-20 to 620°C
-40 to 1140°F
±0.5% of indicated value or ±1°C, whichever is larger
±1digit max.
L12
-100 to 850°C
-100 to 1500°F
-120 to 870°C
-140 to 1540°F
±2°C±1digit max.
U
13
-200 to 400°C
-300 to 700°F
-220 to 420°C
-340 to 740°F
14
-199.9 to 400.0°C
-199.9 to 700.0°F
-199.9 to 420.0°C
-199.9 to 740.0°F
N15
-200 to 1300°C
-300 to 2300°F
-220 to 1320°C
-340 to 2340°F
±0.5% of indicated value or ±1°C, whichever is larger
±1digit max.
(at a temperature of -100°C or less: ±2°C±1digit max.)
R16
0 to 1700°C
0 to 3000°F
-20 to 1720°C
-40 to 3040°F
±0.5% of indicated value or ±1°C, whichever is larger
±1digit max.
(at a temperature of 200°C or less: ±3°C±1digit max.)
S17
0 to 1700°C
0 to 3000°F
-20 to 1720°C
-40 to 3040°F
B18
100 to 1800°C
300 to 3200°F
0 to 1820°C
0 to 3240°F
±0.5% of indicated value or ±1°C, whichever is larger
±1digit max.
(at a temperature of 400°C or less is unrestricted.)
Pulse frequency Setting range Measuring accuracy
30 0.05 to 30Hz (Minimum pulse width: 15ms)
±0.1%FS±1digit max. at 23°C±5°C
5k 0.05 to 5kHz (Minimum pulse width: 90μs)
