A-7
APPENDIX
K3MA-F
Level Parameter Indication Setting range Default Unit
Set
value
Protect
Operation/adjustment lockouts oapt 0-20
Setting level lockout icpt 0-21
Setting change lockout wtpt off/on off
Operation
OUT1 Value out1 :9999-99999 99999
OUT1 upper-limit value out!h :9999-99999 99999
OUT1 lower-limit value out!l :9999-99999 :9999
OUT2 value out2 :9999-99999 :9999
OUT2 upper-limit value outBh :9999-99999 99999
OUT2 lower-limit value outBl :9999-99999 :9999
Initial
setting
Pulse frequency p-fre 30/5k 5k Hz
Scaling input value inp 0-99999 5000
Scaling display value dsp :9999-99999 5000
Decimal point position
dp ,.,,,,/,,.,,,/
,,,.,,/,,,,.,/
,,,,,
,,,,,
OUT1 type out1.t hi/lo/hi-lo hi
OUT2 type out2.t hi/lo/hi-lo lo
Move to advanced-function set-
ting level
amov :9999-99999 0
Advanced-
function
setting
Parameter initialization init off/on off
No. of measurements for
averaging
avg off/2/4/8 off tim
e
OUT1 hysteresis hys1 0-9999 1
OUT2 hysteresis hys2 0-9999 1
Auto-zero time auto.z 0.0-19.9 19.9 s
Startup compensation timer s-tmr 0.0-99.9 0.0 s
Display color change
color grn-r/grn/red-g/
red
grn-r
Display auto-return time ret 0-99 10 s
Move-to-protect-level time prlt 0-19 5 s
APPENDIX
